●LF1740-B4 Flatbed Applicator Front Intelligent Panel
●Operation Is More Intuitive and Convenient
●Adjust Lamination Temperature and Pressure
●Media Roll Holder at end of LF1740-B4 Flatbed Applicator
●Support Lamination Film During Flatbed Laminating
●Integrated Package of LF1740-B4 Flatbed Applicator can Save Transfer Space
●Can Avoid Any Bubbles and Folds during Lamination
●LF1740-B4 Flatbed Applicator Roller use Silicon and Solid Seamless Steel Tube
●Silicon Roller Has Long Time Service Life under High Temperature Lamination
|
Model |
LF1740-B4
|
LF1740-B4
|
|
Lamination Type |
Cold |
Warm & Cold |
|
Lamination Temp |
/ |
0~60°C/0~140°F |
|
Max Lamination Width |
|
|
|
Max Lamination Length |
4000mm/157.48" |
|
|
Max Lamination Thickness |
50mm/1.96''
|
|
|
|
|
|
|
Heating Roller |
Top |
|
|
Roller |
Silicon |
|
|
Diameter of Roller |
130mm |
|
|
Pressure/Height Adjust |
Automatic (Pneumatic Pressure) |
|
|
Working Type |
Manual |
|
|
Certificate |
CE, RCM, ROHS |
|
|
Heating |
Infrared |
|
|
Preheating Time |
10-15 min |
|
|
Voltage
|
110V/220V 50/60Hz
|
|
|
Package Size |
4200*1900*1400mm 8.7CBM |
|
|
Gross Weight |
800KGS |
|
LeFu LF1740-B4 Flatbed Applicator Can be Widely Used in Signage and Graphic Industries, Used Special for Flexible Sign, Board, Irregular Shaped Panels and Banners Etc.
